V-Lock PTO/PTL Monitored 11.4-28VDC

The ES8100 V Lock is a direct retrofit for the Trimec ES8000

• Unlocks under a Pre-Load of up to 100kg in 3-wire mode, 15kg in 2-wire mode
• Locks under a Pre-Load of 20kg (12W) and 35kg (24W)
• Door Position and Lock Status Monitoring
• LED lock status
• IP53 for external door use
• Allows for door misalignment of up to 12mm total (+/-6mm)
• Easy, one-step, Fail Safe (PTL) and Fail Secure (PTO) field selection
• Can be mounted vertically or horizontally (must not be mounted in the floor)
• Operating voltage: 11.4 - 26VDC
